2pc Threaded Ball Valve With Mounting Pad Characteristics:

☆Pressure: 1000PSI/PN63

☆Temperature Range: -29℃＞120℃ （based on the different temperatures between body materials and sealing surface materials）

☆Medium: Using different materials can be applied to water, oil, gas or caustic liquid.

☆Thread Type: G, NPT, PT, Rp, Rc, DIN 259/2999.

☆PED97/23/EC Approved

☆Casting Approved AD2000-W0

☆ISO5211 Mounting Pad

☆Inspection Testing: API598, EN12266

2pc Threaded Ball Valve With Mounting Pad Threaded:BSPT.BSP.NPT.DIN2999.ISO228/1

2pc Threaded Ball Valve With Mounting Pad Materials:CF8M(SS316),CF8(SS304)

Features:

▲Investment casting body

▲Working pressure 800/1000PSI for W.O.G.

▲Adjustable stem packing

▲Pure teflon seals and seats

▲Temperature range:-60 to 450°F

▲Blow-out proof stem,and safe pressure-reducing hole

▲100% leakage tested at 100PSI air under water

▲Hydrostatic test pressure:1500PSI

▲Locking device(optional)

1/4”-3/4” one each, 1”-2” two each

Note: Valves are static grounded by thrust washer and packing

Features:

Full port, investment casting body, fire safe and anti-static devices, blow-out proof stem, double-dish shrapnel automatic compression packing design, cleaning valve chamber device, pressure balance hole in the ball (option), ball valves pneumatic used to high platform design, integrated actuator and valve body connection, no separate bracket, torque reduction, ease of assembly and saving space.
